SMIT 1305 (Load Cell Amplifier)

Name: SMIT 1305 (Load Cell Amplifier)
Brand: SAMYAK INSTRUMENTATION PVT LTD
Price: 4500.0 INR
Availability: InStock

Price 4500.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SMIT 1305 (Load Cell Amplifier) Specification

Features
This is a DIN rail mount unit. It can be field mounted near load cell. As signal is amplified and than transmitted from field, it drastically reduces chances of noise pick up. Output of the amplifier is linearly proportional to weight applied on the sensor.

Output
4-20mA / 0-10VDC (Field configured)

Installation Type
Panel-mounted unit

Usage & Applications
Weighing systems. Tension measurement systems

Product Type
Load cell signal converter SMIT 1305

Working Temperature
10 C to +50 C Celsius (oC)

Input
Load cell (4 wires)

Diameter
112 (W) x 76 (H) x 45 (D) in mm Millimeter (mm)

Application
Weighing systems, Tension measurement systems

Supply Voltage
24 VDC Watt (w)

Operating Temperature
0 C to +60 C Celsius (oC)

Dimension (L*W*H)
112 (W) x 76 (H) x 45 (D) in mm Millimeter (mm)

Phase
Single Phase

Weight
Less than 1 KG Grams (g)

Warranty
1 year

Material
Metallic body with powder-coated finish

SMIT 1305 (Load Cell Amplifier) Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
2 Week

Main Domestic Market
All India

About SMIT 1305 (Load Cell Amplifier)

It can be field mounted near load cell. As the signal is amplified and than transmitted from the field, it drastically reduces the chances ofnoise pick up.

The output of the amplifier is linearly proportional to the weight applied on the sensor.

Operating voltage: 24 VDC

Input: Load cell (4 wires)

Excitation voltage: 10VDC

Operating temperature range: 0 to 60 Deg Cent

Accuracy better than 0.5% of Full scale

Output:

0-20 ma/4-20mA/0 to 1VDC/0-10VDC/0-5VDC (Factoryconfigured)

Enclosure: DIN Rail mounting type, Plastic

Applications:

Weighing systems

Tension measurement systems
